4PN 4" Hermetically Sealed Motor Low Noise Vortex Borehole Submersible Pump

Minimum well diameter : 4"

Oil chamber : Cast-Cu or iron or 420SS

Stainless Steel Strainer
Hermetically Sealed Motor
Low Noise
Vortex Borehole Submersible Pump

PREV：3SV 3" Powerful Long-lasting Vortex Borehole Submersible pump for Water Supply from Wells or Reservoirs
NEXT：3QGD 3" High Sand Resistant Superior Quality 304 SS Strainer Screw Borehole Submersible pump

Description
Components
Curves
Performance Data
Contact Us

Description :

The Vortex Borehole Submersible Pump is a ultimate solution for all your pumping needs. Engineered with precision and reliability in mind, this professional-grade pump is designed to deliver exceptional performance in various applications . Whether you need to pump water from deep boreholes, wells, or underground water sources, this submersible pump is up to the task. Its vortex impeller design allows for the efficient handling of solids and debris, ensuring uninterrupted pumping even in challenging conditions.

Key Features :

1、Equipped with a powerful 4PN 4" hermetically sealed motor, this submersible pump ensures optimal efficiency and durability. Its hermetic sealing guarantees protection against water ingress, preventing any potential damage and ensuring a longer lifespan for the pump.
2、One standout feature of the Vortex Borehole Submersible Pump is its low noise operation. Engineered with advanced noise reduction technology, this pump operates quietly without compromising its powerful performance. Say goodbye to the annoying buzzing and humming sounds typically associated with pumps, and enjoy a peaceful environment.
3、With its professional tone and robust features, the Vortex Borehole Submersible Pump is the ideal choice for professionals in various industries. From agriculture and irrigation to mining and construction, this pump is built to deliver reliable and efficient performance.
4、Invest in the Vortex Borehole Submersible Pump today and experience the difference in quality and performance. With its exceptional features, this pump is the ultimate solution for all your pumping requirements. Trust in its reliability, efficiency, and low noise operation to meet your needs and exceed your expectations.

Operating Conditions :

Maximum fluid temperature up to +35°C
Maximum sand content : 0. 15%
Minimum well diameter : 4"

Motor and Pump :

Rewindable motor
Single-phase:220 - 240V/50Hz
Three-phase: 380 - 415V/50Hz
Single phase motor with built-in capacitor
Curve tolerance according to ISO 9906

Options on request :

Special mechanical seal
Other voltages or frequency 60Hz

Warranty : 2 years

(according to our general sales conditions)

CE Certificate :

Product Line :

Components :

Components	Material
Delivery casing	Plastic.PA
Impeller	Cast-CuASTM C85500
Motor external casing	AISI 304 SS
Oil chamber	Plastic.PA
Bottom support	Plastic.PA
Mechanical seal	Graphite-Ceramic
Shaft	AISI304 SS-ASTM 5140
Seal lubricant oil	Oil for food machinery and pharmaceutic use.

Performance Curves ( 50Hz ) :

Performance Data ( 50Hz ) :

Model		Power		Deliver
1~220-240V	3~380-415V	KW	HP	Q(m³/h)	0	0.3	0.6	0.9	1.2	1.5	1.8
1~220-240V	3~380-415V	KW	HP	Q(l/min)	0	5	10	15	20	25	30
4PNM20	4PN20	0.75	1	H(m)	52	45	38	31	24	17	10
