The KC Series 380V Class F Major Insulation Submersible Pump is a specialized pump designed for agricultural water supply and drainage applications. It is known for its high voltage rating, Class F major insulation, and efficient performance.
The pump is built with Class F major insulation, which ensures enhanced electrical insulation and protection. This insulation rating allows the pump to withstand higher temperatures and provides added safety during operation.
The high efficiency motor of the pump provides sufficient power to handle agricultural water supply and drainage needs. It is capable of pumping water from various sources, such as wells, rivers, or reservoirs, and can be used for irrigation, livestock watering, or drainage purposes.
The submersible design allows the pump to be fully submerged in water, enabling efficient pumping and transport of water from different depths.
Additionally, the KC Series submersible pump may feature built-in protection mechanisms, such as overload protection and automatic shutdown in case of motor failure. These safety features help to prevent damage to the pump and ensure reliable operation.
According to our general sales conditions, one-year-warranty is guaranteed.
Lastly but not least,if you have need with respect to other voltages and the length of cable,please don't hesitate to contact us.
The KC Series 380V Class F Major Insulation Submersible Pump is a reliable and efficient solution for agricultural water supply and drainage needs. Its high voltage rating, Class F insulation, and powerful motor make it suitable for pumping water over long distances or through complex irrigation systems. Whether used for agriculture, livestock, or drainage purposes, this pump provides efficient and reliable water supply and drainage capabilities.
Max: immersion depth : 8m
Max: liquid temperature : 40℃
Insulation class : F
Protection class : IP68
Water depth : 25m
|
Materials Table |
||
|
NO. |
Name |
Material |
|
01 |
Hose coupling |
Cast iron |
|
02 |
Handle |
Steel |
|
05a |
Upper cover |
Cast iron |
|
05b |
Upper cover |
Cast iron |
|
07 |
Bearing house |
Cast iron |
|
10 |
Seal house |
Cast iron |
|
11 |
Motor casing |
Stainless steel |
|
12 |
Outer casing |
Stainless steel |
|
14 |
Impeller |
Chrome steel |
|
15 |
Diffuser |
Cast iron |
|
25 |
Strainer |
AISI201SS |
|
27 |
Stator |
|
|
28 |
Rotor |
Shaft : AISI420SS |
|
31a |
Bearing |
Ball bearing |
|
31b |
Bearing |
Ball bearing |
|
33 |
Motor protector |
|
|
34 |
Mechanical seal |
Sic-Sic / Sic-Sic ( 3.7-5.5kw ) |
|
Sic-Sic/Carbon-Sic ( ≤2.2kW) |
||
|
35 |
Oil seal |
|
|
47 |
Cable |
H07RN-F |
