The HRS25/6GF Series Supply Iron Flange Ceramic Shaft Water Circulation Pump , designed for optimal performance , is perfect for heating systems in city mansions and suburban villas. With its industrial-grade capabilities, it seamlessly matches with various industrial equipment, providing efficient water circulation for cooling air-conditioning units, boilers, and even solar energy systems. Not only does this pump excel in supplying hot water, but it also excels in maintaining warmth, ensuring a comfortable environment throughout. Experience the reliability and efficiency of the HRS25/6GF Series Supply Iron Flange Ceramic Shaft Water Circulation Pump, the perfect choice for your heating and water supply needs.
Applications:
Heating systems in residential and commercial buildings
Industrial equipment cooling
Solar water heating systems
Boiler circulation systems
Flow Rate: Up to 9.6 m³/h
Head: Up to 8 meters
Pressure: Up to 10 bar
Ambient Temperature: 0℃~40℃
Ambient Humidity: 95%
Liquid Temperature: -10℃~110℃
Motor: Copper-wound with thermal protection
Shaft Material: Ceramic
Bearing Material: Ceramic
Impeller Material: Polypropylene
Connection: Flange mount
Voltage and Frequency: Customizable (50Hz or 60Hz)
|
Model |
Power |
Max. Flow |
Max. Head |
Voltage |
Pump Dimension (mm) |
Flange Dimension (mm) |
Weight (kg) |
||||||||
|
W |
(m³/h) |
(m) |
220V/50Hz |
220V/60Hz |
127V/60Hz |
L |
B |
H |
G |
D1 |
D2 |
D3 |
D4 |
||
|
HRS25/6GF |
93 |
3.5 |
6 |
★ |
★ |
★ |
166 |
118 |
154 |
11/2” |
106 |
67 |
13.5 |
80 |
3.0 |
|
HRS25/6GF |
67 |
2.3 |
5 |
★ |
★ |
★ |
166 |
118 |
154 |
11/2” |
106 |
67 |
13.5 |
80 |
3.0 |
|
HRS25/6GF |
46 |
1.3 |
3 |
★ |
★ |
★ |
166 |
118 |
154 |
11/2” |
106 |
67 |
13.5 |
80 |
3.0 |
Installation Dimension :
