The VW submersible pump is made of stainless steel and cast iron for corrosion resistance, with a built-in vortex impeller and large channel to handle liquids containing foreign bodies, ideal for wastewater drainage in factories, construction sites, sewage treatment plants, and municipal/irrigation applications.
Application :
It efficiently manages wastewater drainage across industrial factories, busy construction sites, and commercial facilities, ensuring uninterrupted operations and compliance with environmental standards.
It integrates seamlessly into the drainage systems of municipal sewage treatment plants, supporting the reliable processing and conveyance of raw and treated sewage.
It provides stable performance for drainage stations in residential quarters, safeguarding the daily living environment by effectively removing excess water and sewage.
It also addresses specialized applications such as liquid handling in methane pools and agricultural field irrigation in rural areas, demonstrating its versatility in both industrial and agricultural contexts.
Max immersion depth: 5m
Max liquid temperature: 40℃
Liquid PH value: 5-9
Liquid kinematic ciscosity : 7×10-6~23×10-6m²/s
Max. liquid density : 1.2×10³kg/m³
Copper winding
Built-in thermal protector
Insulation class : B
Protection class : IPX8
Float switch：Available upon request, it allows for automatic control of water levels, ensuring the pump operates only when necessary and preventing over-pumping or under-pumping.
Other voltage or frequency：Customizable options are available to meet specific electrical requirements, ensuring compatibility with different power sources.
(according to our general sales conditions)
|
NO. |
NAME |
MATERIAL/SPEC. |
|
1 |
Handel |
Stainless steel |
|
2 |
Capacitor Cover |
HT200 |
|
3 |
Screw |
Stainless steel |
|
4 |
O RING |
NBR |
|
5 |
Upper Cover |
HT200 |
|
6 |
O Ring |
NBR |
|
7 |
Float Switch(Optional) |
|
|
8 |
Motor |
AISI201 (Motor casing) |
|
9 |
Rotor |
45#Carbon steel & 2Cr13 Stainless |
|
10 |
Oil Chamber |
HT200 |
|
11 |
Oil Chamber Cover |
HT200 |
|
12 |
Oil Seal |
NBR |
|
13 |
Impeller |
HT200 |
|
14 |
Key |
Stainless Steel |
|
15 |
Filter Mesh |
ST13 |
|
16 |
Shaft Sleeve |
HT200 |
|
17 |
Pump Body |
HT200 |
|
18 |
Out-let Connector |
ABS |
|
19 |
Bearing |
|
|
20 |
Bearing |
|
|
21 |
Capacitor |
|
|
22 |
Cable Protector |
|
