The 4HVSC Wide Voltage Solar Deep Well Pump features a 4-inch diameter design and a wide-voltage brushless DC motor, delivering energy-efficient and reliable water pumping for homes and small agricultural projects. Equipped with a stainless steel impeller and cylinder, the pump provides outstanding corrosion resistance and long-term durability, even in wells with low sand content. Intelligent control functions, including soft start and water shortage protection, ensure stable operation and prevent damage in challenging environments.
Wide-Voltage Brushless DC Motor: Ensures stable, energy-saving performance under variable solar power conditions.
Stainless Steel Impeller & Cylinder: Durable, corrosion-resistant construction for reliable deep well pumping.
4-Inch Bore Design: Suitable for moderate water flow requirements in households and small farms.
Intelligent Controller: Supports soft start and water shortage protection to prevent operational damage.
Low Maintenance & High Efficiency: Optimized for long-term operation in off-grid and solar-powered environments.
Household drinking water supply in rural or off-grid areas
Energy-efficient agricultural irrigation for small farms and orchards
Rural community water systems
Solar-powered water transfer and storage
Reliable deep well pumping in low-sand-content wells
| ITEM | (AC) Voltage | Optimum input voltage (DC) | Power | Max. Flow | Max. Head | Outlet | Cable | Solar panel - Open circuit voltage (VOC) |
Solar panel - Power |
| 4ADSC3.5-105-110-750 | 85V-280V | 100V-350V | 750W | 3.5m³/h | 105m | 1.25" | 2m | <430V | ≥1.3*PUMP POWER |
| 4HVSC3.5-105-110-750 | / | 100V-350V | 750W | 3.5m³/h | 105m | 1.25" | 2m | <430V | ≥1.3*PUMP POWER |
| 4ADSC3.5-140-110-1100 | 85V-280V | 110V-350V | 750W | 3.5m³/h | 140m | 1.25" | 2m | <430V | ≥1.3*PUMP POWER |
| 4HVSC3.5-140-110-1100 | / | 110V-350V | 750W | 3.5m³/h | 140m | 1.25" | 2m | <430V | ≥1.3*PUMP POWER |
| 4ADSC4.8-203-150-1500 | 85V-280V | 150V-350V | 1500W | 4.8m³/h | 203m | 1.25" | 2m | <430V | ≥1.3*PUMP POWER |
| 4HVSC4.8-203-150-1500 | / | 150V-350V | 1500W | 4.8m³/h | 203m | 1.25" | 2m | <430V | ≥1.3*PUMP POWER |
| 4ADSC6-67-110-750 | 85V-280V | 100V-350V | 750W | 6m³/h | 67m | 1.25" | 2m | <430V | ≥1.3*PUMP POWER |
| 4HVSC6-67-110-750 | / | 100V-350V | 750W | 6m³/h | 67m | 1.25" | 2m | <430V | ≥1.3*PUMP POWER |
| 4ADSC6-101-110-1100 | 85V-280V | 110V-350V | 1100W | 6m³/h | 101m | 1.25" | 2m | <430V | ≥1.3*PUMP POWER |
| 4HVSC6-101-110-1100 | / | 110V-350V | 1100W | 6m³/h | 101m | 1.25" | 2m | <430V | ≥1.3*PUMP POWER |
| 4ADSC6-146-110-1300 | 85V-280V | 110V-350V | 1300W | 6m³/h | 146m | 1.25" | 2m | <430V | ≥1.3*PUMP POWER |
| 4HVSC6-146-110-1300 | / | 110V-350V | 1300W | 6m³/h | 146m | 1.25" | 2m | <430V | ≥1.3*PUMP POWER |
| 4ADSC15-45-110-750 | 85V-280V | 100V-350V | 750W | 15m³/h | 45m | 2" | 2m | <430V | ≥1.3*PUMP POWER |
| 4HVSC15-45-110-750 | / | 100V-350V | 750W | 15m³/h | 45m | 2" | 2m | <430V | ≥1.3*PUMP POWER |
| 4ADSC15-55-110-1100 | 85V-280V | 110V-350V | 1100W | 15m³/h | 55m | 2" | 2m | <430V | ≥1.3*PUMP POWER |
| 4HVSC15-55-110-1100 | / | 110V-350V | 1100W | 15m³/h | 55m | 2" | 2m | <430V | ≥1.3*PUMP POWER |
| 4ADSC16-70-150-1500 | 85V-280V | 150V-350V | 1500W | 16m³/h | 70m | 2" | 2m | <430V | ≥1.3*PUMP POWER |
| 4HVSC16-70-150-1500 | / | 150V-350V | 1500W | 16m³/h | 70m | 2" | 2m | <430V | ≥1.3*PUMP POWER |
| 4ADSC20-48-150-1500 | 85V-280V | 150V-350V | 1500W | 20m³/h | 48m | 2" | 2m | <430V | ≥1.3*PUMP POWER |
| 4HVSC20-48-150-1500 | / | 150V-350V | 1500W | 20m³/h | 48m | 2" | 2m | <430V | ≥1.3*PUMP POWER |
| ITEM | (AC) Voltage | Optimum input voltage (DC) | Power | Max. Flow | Max. Head | Outlet | Cable | Solar panel - Open circuit voltage (VOC) |
Solar panel - Power |
| 4ADSC9.5-50-110-750 | 85V-280V | 100V-350V | 750W | 9.5m³/h | 50m | 2" | 2m | <430V | ≥1.3*PUMP POWER |
| 4HVSC9.5-50-110-750 | / | 100V-350V | 750W | 9.5m³/h | 50m | 2" | 2m | <430V | ≥1.3*PUMP POWER |
| 4ADSC9.5-75-110-1100 | 85V-280V | 110V-350V | 1100W | 9.5m³/h | 75m | 2" | 2m | <430V | ≥1.3*PUMP POWER |
| 4HVSC9.5-75-110-1100 | / | 110V-350V | 1100W | 9.5m³/h | 75m | 2" | 2m | <430V | ≥1.3*PUMP POWER |
| 4ADSC9.5-90-150-1500 | 85V-280V | 150V-350V | 1500W | 9.5m³/h | 90m | 2" | 2m | <430V | ≥1.3*PUMP POWER |
| 4HVSC9.5-90-150-1500 | / | 150V-350V | 1500W | 9.5m³/h | 90m | 2" | 2m | <430V | ≥1.3*PUMP POWER |
| 4ADSC25-26-150-1500 | 85V-280V | 150V-350V | 1500W | 25m³/h | 26m | 2" | 2m | <430V | ≥1.3*PUMP POWER |
| 4HVSC25-26-150-1500 | / | 150V-350V | 1500W | 25m³/h | 26m | 2" | 2m | <430V | ≥1.3*PUMP POWER |
| ITEM | (AC) Voltage | Optimum input voltage (DC) | Power | Max. Flow | Max. Head | Outlet | Cable | Solar panel - Open circuit voltage (VOC) |
Solar panel - Power |
| 4ADSC6-255-200-2200 | 85V-280V | 200V-350V | 2200W | 6m³/h | 255m | 1.25" | 2m | <430V | ≥1.3*PUMP POWER |
| 4HVSC6-255-200-2200 | / | 200V-350V | 2200W | 6m³/h | 255m | 1.25" | 2m | <430V | ≥1.3*PUMP POWER |
| 4ADSC6-300-245-3000 | 85V-280V | 245V-350V | 3000W | 6m³/h | 300m | 1.25" | 2m | <430V | ≥1.3*PUMP POWER |
| 4HVSC6-300-245-3000 | / | 245V-350V | 3000W | 6m³/h | 300m | 1.25" | 2m | <430V | ≥1.3*PUMP POWER |
| 4ADSC6-360-300-4000 | 120V-280V | 300V-350V | 4000W | 6m³/h | 360m | 1.25" | 2m | <430V | ≥1.3*PUMP POWER |
| 4ADSC9.5-136-200-2200 | 85V-280V | 200V-350V | 2200W | 9.5m³/h | 136m | 2" | 2m | <430V | ≥1.3*PUMP POWER |
| 4HVSC9.5-136-200-2200 | / | 200V-350V | 2200W | 9.5m³/h | 136m | 2" | 2m | <430V | ≥1.3*PUMP POWER |
| 4ADSC9.5-220-245-3000 | 85V-280V | 245V-350V | 3000W | 9.5m³/h | 220m | 2" | 2m | <430V | ≥1.3*PUMP POWER |
| 4HVSC9.5-220-245-3000 | / | 245V-350V | 3000W | 9.5m³/h | 220m | 2" | 2m | <430V | ≥1.3*PUMP POWER |
| 4ADSC9.5-275-300-4000 | 120V-280V | 300V-350V | 4000W | 9.5m³/h | 275m | 2" | 2m | <430V | ≥1.3*PUMP POWER |
| 4ADSC18-95-200-2200 | 85V-280V | 200V-350V | 2200W | 18m³/h | 95m | 2" | 2m | <430V | ≥1.3*PUMP POWER |
| 4HVSC18-95-200-2200 | / | 200V-350V | 2200W | 18m³/h | 95m | 2" | 2m | <430V | ≥1.3*PUMP POWER |
| 4ADSC18-137-245-3000 | 85V-280V | 245V-350V | 3000W | 18m³/h | 137m | 2" | 2m | <430V | ≥1.3*PUMP POWER |
| 4HVSC18-137-245-3000 | / | 245V-350V | 3000W | 18m³/h | 137m | 2" | 2m | <430V | ≥1.3*PUMP POWER |
| 4ADSC18-168-300-4000 | 120V-280V | 300V-350V | 4000W | 18m³/h | 168m | 2" | 2m | <430V | ≥1.3*PUMP POWER |
| 4ADSC20-70-200-2200 | 85V-280V | 200V-350V | 2200W | 20m³/h | 70m | 2" | 2m | <430V | ≥1.3*PUMP POWER |
| 4HVSC20-70-200-2200 | / | 200V-350V | 2200W | 20m³/h | 70m | 2" | 2m | <430V | ≥1.3*PUMP POWER |
| 4ADSC20-82-245-3000 | 85V-280V | 245V-350V | 3000W | 20m³/h | 82m | 2" | 2m | <430V | ≥1.3*PUMP POWER |
| 4HVSC20-82-245-3000 | / | 245V-350V | 3000W | 20m³/h | 82m | 2" | 2m | <430V | ≥1.3*PUMP POWER |
| ITEM | (AC) Voltage | Optimum input voltage (DC) | Power | Max. Flow | Max. Head | Outlet | Cable | Solar panel - Open circuit voltage (VOC) |
Solar panel - Power |
| 4ADSC22-115-300-4000 | 120V-280V | 300V-350V | 4000W | 22m³/h | 115m | 2" | 2m | <430V | ≥1.3*PUMP POWER |
| 4ADSC30-36-200-2200 | 85V-280V | 200V-350V | 2200W | 30m³/h | 36m | 2" | 2m | <430V | ≥1.3*PUMP POWER |
| 4HVSC30-36-200-2200 | / | 200V-350V | 2200W | 30m³/h | 36m | 2" | 2m | <430V | ≥1.3*PUMP POWER |
| 4ADSC30-52-245-3000 | 85V-280V | 245V-350V | 3000W | 30m³/h | 52m | 2" | 2m | <430V | ≥1.3*PUMP POWER |
| 4HVSC30-52-245-3000 | / | 245V-350V | 3000W | 30m³/h | 52m | 2" | 2m | <430V | ≥1.3*PUMP POWER |
| 4ADSC30-74-300-4000 | 120V-280V | 300V-350V | 4000W | 30m³/h | 74m | 2" | 2m | <430V | ≥1.3*PUMP POWER |
