The 4HVSCW Wide Voltage Solar Submersible Pump features a 4-inch diameter design and a wide-voltage brushless DC water-filled motor, providing stable and energy-efficient operation under variable solar power conditions. Equipped with a stainless steel cylinder and stainless steel impeller, this pump delivers outstanding corrosion resistance and long-term durability for submersible deep well applications. NSK bearings ensure smooth operation and reduced friction, making it an ideal solution for residential, agricultural, and rural water supply systems.
Wide-Voltage Brushless DC Water-Filled Motor: Ensures reliable, energy-efficient performance in solar or DC-powered environments.
Stainless Steel Cylinder & Impeller: Corrosion-resistant for long-term durability and smooth water flow.
NSK Bearings: Provide low-friction operation, enhancing stability and extending pump lifespan.
Submersible 4-Inch Bore Design: Suitable for deep well installations with moderate water flow requirements.
Durable & Low Maintenance: Optimized for long-term use in off-grid and challenging environments.
Solar-powered deep well irrigation for farms, orchards, and greenhouses
Rural household and community drinking water supply
Livestock and pasture watering systems
Off-grid or remote water pumping projects
Reliable submersible pumping in challenging water conditions
| ITEM | (AC) Voltage | (DC) Voltage | Power | Max. Flow | Max. Head | Outlet | Cable | Solar panel - Open circuit voltage(VOC) |
Solar panel - Power |
| 4ADSCW5.2-67-110-750 | 85V-280V | 80V-430V | 750W | 5.2m³/h | 67m | 1.25" | 2m | <430V | ≥1.3*PUMP POWER |
| 4HVSCW5.2-67-110-750 | / | 80V-430V | 750W | 5.2m³/h | 67m | 1.25" | 2m | <430V | ≥1.3*PUMP POWER |
| 4ADSCW4.8-203-200-1500 | 85V-280V | 80V-430V | 1500W | 4.8m³/h | 203m | 1.25" | 2m | <430V | ≥1.3*PUMP POWER |
| 4HVSCW4.8-203-200-1500 | / | 80V-430V | 1500W | 4.8m³/h | 203m | 1.25" | 2m | <430V | ≥1.3*PUMP POWER |
| 4ADSCW5.2-101-150-1100 | 85V-280V | 80V-430V | 1100W | 5.2m³/h | 101m | 1.25" | 2m | <430V | ≥1.3*PUMP POWER |
| 4HVSCW5.2-101-150-1100 | / | 80V-430V | 1100W | 5.2m³/h | 101m | 1.25" | 2m | <430V | ≥1.3*PUMP POWER |
| 4ADSCW5.2-146-200-1300 | 85V-280V | 80V-430V | 1300W | 5.2m³/h | 146m | 1.25" | 2m | <430V | ≥1.3*PUMP POWER |
| 4HVSCW5.2-146-200-1300 | / | 80V-430V | 1300W | 5.2m³/h | 146m | 1.25" | 2m | <430V | ≥1.3*PUMP POWER |
| 4ADSCW7.5-80-150-1300 | 85V-280V | 80V-430V | 1300W | 7.5m³/h | 80m | 1.25" | 2m | <430V | ≥1.3*PUMP POWER |
| 4HVSCW7.5-80-150-1300 | / | 80V-430V | 1300W | 7.5m³/h | 80m | 1.25" | 2m | <430V | ≥1.3*PUMP POWER |
| 4ADSCW7.5-100-200-1500 | 85V-280V | 80V-430V | 1500W | 7.5m³/h | 100m | 1.25" | 2m | <430V | ≥1.3*PUMP POWER |
| 4HVSCW7.5-100-200-1500 | / | 80V-430V | 1500W | 7.5m³/h | 100m | 1.25" | 2m | <430V | ≥1.3*PUMP POWER |
| 4ADSCW11-60-200-1500 | 85V-280V | 80V-430V | 1500W | 11m³/h | 60m | 2" | 2m | <430V | ≥1.3*PUMP POWER |
| 4HVSCW11-60-200-1500 | / | 80V-430V | 1500W | 11m³/h | 60m | 2" | 2m | <430V | ≥1.3*PUMP POWER |
| 4ADSCW19-35-200-1500 | 85V-280V | 80V-430V | 1500W | 19m³/h | 35m | 2" | 2m | <430V | ≥1.3*PUMP POWER |
| 4HVSCW19-35-200-1500 | / | 80V-430V | 1500W | 19m³/h | 35m | 2" | 2m | <430V | ≥1.3*PUMP POWER |
| 4ADSCW25-26-200-1500 | 85V-280V | 80V-430V | 1500W | 25m³/h | 26m | 2" | 2m | <430V | ≥1.3*PUMP POWER |
| 4HVSCW25-26-200-1500 | / | 80V-430V | 1500W | 25m³/h | 26m | 2" | 2m | <430V | ≥1.3*PUMP POWER |
| ITEM | (AC) Voltage | (DC) Voltage | Power | Max. Flow | Max. Head | Outlet | Cable | Solar panel - Open circuit voltage(VOC) |
Solar panel - Power |
| 4ADSCW5.2-255-300-2200 | 85V-280V | 80V-430V | 2200W | 5.2m³/h | 255m | 1.25" | 2m | <430V | ≥1.3*PUMP POWER |
| 4HVSCW5.2-255-300-2200 | / | 80V-430V | 2200W | 5.2m³/h | 255m | 1.25" | 2m | <430V | ≥1.3*PUMP POWER |
| 4ADSCW7.5-150-300-2200 | 85V-280V | 80V-430V | 2200W | 7.5m³/h | 150m | 1.25" | 2m | <430V | ≥1.3*PUMP POWER |
| 4HVSCW7.5-150-300-2200 | / | 80V-430V | 2200W | 7.5m³/h | 150m | 1.25" | 2m | <430V | ≥1.3*PUMP POWER |
| 4ADSCW11-120-300-2200 | 85V-280V | 80V-430V | 2200W | 11m³/h | 120m | 2" | 2m | <430V | ≥1.3*PUMP POWER |
| 4HVSCW11-120-300-2200 | / | 80V-430V | 2200W | 11m³/h | 120m | 2" | 2m | <430V | ≥1.3*PUMP POWER |
| 4ADSCW19-60-300-2200 | 85V-280V | 80V-430V | 2200W | 19m³/h | 60m | 2" | 2m | <430V | ≥1.3*PUMP POWER |
| 4HVSCW19-60-300-2200 | / | 80V-430V | 2200W | 19m³/h | 60m | 2" | 2m | <430V | ≥1.3*PUMP POWER |
| 4ADSCW30-36-300-2200 | 85V-280V | 80V-430V | 2200W | 30m³/h | 36m | 2" | 2m | <430V | ≥1.3*PUMP POWER |
| 4HVSCW30-36-300-2200 | / | 80V-430V | 2200W | 30m³/h | 36m | 2" | 2m | <430V | ≥1.3*PUMP POWER |
