The 4HVPC Wide Voltage Solar Deep Well Pump features a 4-inch diameter design with a wide-voltage brushless DC motor, enabling efficient and reliable operation in solar-powered environments. The pump body is constructed with a copper cylinder and copper outlet, providing outstanding wear and corrosion resistance for stable long-term performance. Its lightweight plastic impeller reduces energy consumption while maintaining smooth water flow, making it ideal for small- to medium-sized solar water supply systems.
Wide Voltage Brushless DC Motor: Ensures stable and energy-efficient operation under variable solar power conditions.
Copper Cylinder & Outlet: Enhances durability, corrosion resistance, and reliable deep well performance.
Plastic Impeller: Lightweight design reduces energy consumption and ensures smooth water flow.
Motor Protection Features: Built-in protection against overcurrent, overpressure, and water shortage for safe operation.
Compact 4-Inch Bore: Suitable for a variety of solar water pumping applications.
Energy-Efficient & Low Maintenance: Optimized for long-term, reliable use in off-grid or rural environments.
Applications :
Rural drinking water supply and household water systems
Small- to medium-scale agricultural irrigation
Solar-powered off-grid water supply projects
Water transfer and storage for remote or challenging locations
Energy-saving deep well pumping in residential or farming applications
| ITEM | (AC) Voltage | Optimum input voltage (DC) | Power | Max. Flow | Max. Head | Outlet | Cable | Solar panel -Open circuit voltage (VOC) | Solar panel - Power |
| 4HVPC7-150-200-2200 | / | 200V-350V | 2200W | 7m³/h | 185m | 2" | 2m | <430V | ≥1.3*PUMP POWER |
| 4HVPC7-175-245-3000 | / | 245V-350V | 3000W | 7m³/h | 230m | 2" | 2m | <430V | ≥1.3*PUMP POWER |
| 4HVPC9.5-125-200-2200 | / | 200V-350V | 2200W | 9.5m³/h | 125m | 2" | 2m | <430V | ≥1.3*PUMP POWER |
| 4HVPC9.5-150-245-3000 | / | 245V-350V | 3000W | 9.5m³/h | 195m | 2" | 2m | <430V | ≥1.3*PUMP POWER |
| 4HVPC12-150-200-2200 | / | 200V-350V | 2200W | 12m³/h | 150m | 2" | 2m | <430V | ≥1.3*PUMP POWER |
| 4HVPC12-175-245-3000 | / | 245V-350V | 3000W | 12m³/h | 175m | 2" | 2m | <450V | ≥1.3*PUMP POWER |
| 4HVPC14-125-200-2200 | / | 200V-350V | 2200W | 14m³/h | 125m | 2" | 2m | <450V | ≥1.3*PUMP POWER |
| 4HVPC14-150-245-3000 | / | 245V-350V | 3000W | 14m³/h | 150m | 2" | 2m | <450V | ≥1.3*PUMP POWER |
| ITEM | (AC) Voltage | Optimum input voltage (DC) | Power | Max. Flow | Max. Head | Outlet | Cable | Solar panel -Open circuit voltage (VOC) | Solar panel - Power |
| 4HVPC18-112-345-3000 | / | 240V-350V | 3000W | 18m³/h | 112m | 2" | 2m | <450V | ≥1.3*PUMP POWER |
| 4HVPC22-78-245-3000 | / | 240V-350V | 3000W | 22m³/h | 78m | 2" | 2m | <450V | ≥1.3*PUMP POWER |
| 4HVPC30-50-200-2200 | / | 200V-350V | 2200W | 30m³/h | 50m | 2" | 2m | <450V | ≥1.3*PUMP POWER |
| 4HVPC30-60-245-3000 | / | 245V-350V | 3000W | 30m³/h | 60m | 2" | 2m | <450V | ≥1.3*PUMP POWER |
| 4HVPC36-45-200-2200 | / | 200V-350V | 2200W | 36m³/h | 45m | 2" | 2m | <450V | ≥1.3*PUMP POWER |
| 4HVPC41-52-245-3000 | / | 245V-350V | 3000W | 41m³/h | 52m | 2" | 2m | <450V | ≥1.3*PUMP POWER |
