3YSM 3" Class F Insulation Single-phase Rewindable Borehole Submersible Motor for Domestic Use

Minimum well diameter : 3"
Oil chamber : Cast-iron or Cu
Speed : 2850rpm
Insulation class : F
Protection grade : IP 68

PREV：8SP77 8" Large Water Outlet Mass Discharge Three -phase Borehole Submersible Pump with 304SS Impeller
NEXT：4YS 4" High Temperature Power Off Fuction Mechanical Seal Borehole Submersible Motor

Description
Components
Curves
Performance Data
Contact Us

Description :

Designed with utmost precision and engineering excellence, the 3YSM 3" Class F Insulation Single-phase Rewindable Motor Borehole Submersible Motor is a remarkable addition to our range of high-quality motors. This motor is specifically crafted to meet the demands of borehole submersible applications, ensuring reliable and efficient performance.

Key Features :

1、One of the standout features of this motor is its Class F insulation, which guarantees exceptional thermal resistance and insulation properties. This ensures that the motor can withstand high temperatures and operate smoothly even in challenging environments. With this motor, you can have peace of mind knowing that it will deliver consistent performance, regardless of the conditions.
2、The 3YSM 3" Class F Insulation Single-phase Rewindable Motor Borehole Submersible Motor is also designed for easy maintenance and repair.
3、Its rewindable feature allows for convenient access to the winding, making it easier to carry out any necessary repairs or replacements. This ensures minimal downtime and reduces the overall cost of ownership.
4、This motor boasts a compact design, making it suitable for installation in narrow boreholes. Its 3" size allows for seamless integration into various applications, without compromising on performance or efficiency. Whether you need to pump water from deep wells or irrigate agricultural fields, this motor is built to deliver optimal results.

Operating Conditions :

Speed : 2850rpm
Insulation class : F
Protection grade:IP 68
Maximum fluid temperature up to +35℃
Minimum well diameter : 3"

Motor and Pump :

Rewindable motor
Single-phase : 220-240V/50Hz
Equip with start control box or digital auto-control box

Options on request :

Special mechanical seal
Other voltages or frequency 60Hz
Single phase motor with inside capaciter

Warranty : 2 years

(according to our general sales conditions)

CE Certificate :

Product Line :

Components and Material :

Components	Material
Motor external casing	AISI 304 SS
Oil chamber	①Cast-Cu ASTM C85500
Oil chamber	②Cast-iron ASTM N0.30
Bottom support	AISI 304 SS
Mechanical seal	Special seal for deep well(Graphite-Ceramic)
Shaft	AISI 304 SS-ASTM5140
Seal lubricant oil	Oil for food machinery and pharmaceutic use.

Technical Data :
