The 6SR30 6" Sand Prevention Electrophoretic Cast Iron Pump Head Raised Base Borehole Submersible Pump is a robust and efficient water pumping solution designed for borehole applications. This pump features a sand prevention design, an electrophoretic cast iron pump head, and a raised base.
1、The sand prevention design of the pump helps to prevent clogging and damage caused by sand and other abrasive particles commonly found in boreholes. This ensures smooth and uninterrupted water pumping, even in challenging environments.
2、The electrophoretic cast iron pump head provides durability and resistance to corrosion. This material is known for its strength and longevity, making it suitable for long-term use in various water conditions.
3、The raised base of the pump helps to protect the motor and other components from potential water damage. It elevates the pump above the bottom of the borehole, reducing the risk of water infiltration and extending the lifespan of the pump.
4、The 6SR30 pump is specifically designed for borehole applications, allowing it to be fully submerged in water. This submersible design maximizes efficiency and minimizes noise, making it suitable for various settings including residential, commercial, or agricultural.
5、Maximum fluid temperature up to +35℃
6、Maximum sand content : 0.25%
7、Minimum well diameter : 6"
Rewindable Electric Motor
Single-phase : 220-240V/50Hz
Three-phase : 380-415V/50Hz
①Direct-On-Line Starting - 1 Cable
②Star-Delta Starting - 2 Cables
Equipped with a Starting Control Box or a Digital Auto-Control Box
Conforms to NEMA Dimensional Standards
Curve Tolerance accordance with ISO 9906
Special mechanical seal
Other voltages or frequency 60Hz
Warranty : 2 years
(according to our general sales conditions)
Components and Material :
| Components | Material |
| Pump external casing | AISI 304 SS |
| Delivery casing | Cast-Cu ASTM NO.30 |
| Suction lantern | Cast-Cu ASTM NO.30 |
| Diffuser | Plastic.PC & AISI 304 SS |
| Impeller | Plastic.PC |
| Shaft | AISI 304 SS |
| Shaft coupling | AISI 304 SS |
| Wear ring | AISI 304 SS |
| Motor external casing | AISI 304 SS |
| Top chock | Cast-iron ASTM NO.30 |
| Bottom support | Cast-iron ASTM NO.30 |
| Seal | NBR Graph-SIC/TC |
| Shaft | AISI 304 SS-ASTM 5140 |
