Main Features：
1、 Oil-filled AC/DC motor : Minimize the number of solar panels in order to save energy but no loss of efficiency
2、Stainless steel outlet/connector/ oil cylinder:Ensures that the pump operates smoothly and quietly, while the stainless steel impeller ensures durability and longevity.
3、 Japanese NSK bearing : ensuring that you get the most out of your investment
4、 Silicon carbide-impregnated graphite
5、 Automatic winding machine with 180°C high temperature resistant copper wire, insulation class F.
6、 The pump operates smoothly and quietly that makes you have a confortable circulation.
7、Installation easily : It is easy to install and operate, making it a convenient option for those who need a reliable water pumping solution.
8、The magnet is made of 40SH NdFeb, with a temperature resistance of 150℃.
9、 AC/DC Controller :
1) Waterproof grade : IP65
2) Tolerable temperature : -15℃ to 60℃
3) MPPT function , In essence, the frequency conversion technology, the maximum power point tracking technology of photovoltaic array
4) Automatic charging function : The battery can sustain the motor whenever in sunny or not
5) You will see the condition of the pump by LED screen
6) Reliable conversion function:If you want to control it by your hand,the pump can also satisfy you
7) Automatically start and stop working,with water protection.
8) Water proof and leak-proof: Prevent water from coming in or out the motor
9) Soft start: No impulse current and vibration-free
10) High voltage/Low voltage/Over-current/High temperature protection.
11)Automatic startup and shutdown, without personnel on duty.
Spare parts:
Installation Tutorial :
How to choose the Solar Panel：
Components & Material：
| Components | Material |
| Outlet | Stainless Steel |
| Connection | Stainless Steel |
| Oil cylinder | Stainless Steel |
| Impeller | Stainless Steel |
| Bearing | NSK |
| Shaft | Complete SS304 |
Hydraulic Performance Curves：
Technical Data：
|
ITEM |
(AC) Voltage |
(DC) Voltage |
Power |
Max.Flow |
Max.Head |
Outlet |
Cable |
Solar panel |
|
|
Open circuit voltage (VOC) |
Power |
||||||||
|
3ADSC4.8-95-72-750 |
85V-280V |
100V-350V |
750W |
4.8m3/h |
95m |
1.25" |
2m |
<430V |
≥1.3*PUMP POWER |
|
3ADSC5-112-110-1100 |
85V-280V |
110V-350V |
1100W |
5m3/h |
112m |
1.25" |
2m |
<430V |
≥1.3*PUMP POWER |
|
3ADSC5-135-110-1500 |
85V-280V |
110V-350V |
1500W |
5m3h |
135m |
1.25" |
2m |
<430V |
≥1.3*PUMP POWER |
